Low Power CC1310 RF 434 MHz RTS Module UFL Connector 700m Reach

Name: Low Power CC1310 RF 434 MHz RTS Module UFL Connector 700m Reach
Brand: Cansec Wireless
Price: 4.12 USD

China Low Power CC1310 RF 434 MHz RTS Module UFL Connector 700m Reach wholesale

Brand Name : Cansec Wireless

Model Number : AN1310UA-A

Place of Origin : Beijing

MOQ : 100

Price : USD 4.12$ per piece

Payment Terms : T/T

Supply Ability : 2000000 pieces per year

Delivery Time : 5~8 weeks

Packaging Details : Box for 1000 pieces Package size: 40*34*20 cm Gross weight: 5.000 kg

size : 15mm*22mm*3.2mm

TX Power : 13dBm

RX sensitivity : -124dBm

TX current : 25mA

RX current : 5.5mA

Standby current : 1uA

Antenna : UFL Connector

Chipset : CC1310 by Texas Instruments

Frequency : 434/470/868/915MHz

Reach : 700m

Working Tempurature : -20~+70℃

Contact Now

Cansec Low Power CC1310 RF 434 MHz Wireless Module Industrial Control Wireless Module

Low Power CC1310 RF 434 MHz RTS Module UFL Connector 700m Reach

Vbat=3.3V Fquency=434/470MHz

Parameter		Min	Typ	Max	Unit
Operating Voltage		1.8	-	3.8	V
Operating Temperature		-20	-	+70	℃
Current Consumption	Sleep Mode	-	-	1	uA
	Receive mode	-	5.5	-	mA
	Transmit Mode (For Carrier &&UFL Connector)	-	35	38	mA
TX Power (For Carrier)		-	13	14	dBm
RX Sensitivity		-	-	-124	dBm
Distance(434M)		400			m

Vbat=3.3V Fquency=868/915MHz

Parameter		Min	Typ	Max	Unit
Operating Voltage		1.8	-	3.8	V
Operating Temperature		-20	-	+70	℃
Current Consumption	Sleep Mode	-	-	1	uA
	Receive mode	-	5.5	-	mA
	Transmit Mode (For Carrier &&UFL Connector)	-	34	36	mA
TX Power (For Carrier)		-	13	14	dBm
RX Sensitivity		-	-	-115	dBm
Distance(868M)		700			m

Cansec Low Power CC1310 RF 434 MHz Wireless Module Industrial Control Wireless Module

The AN1310 module is designed based on CC1310F128. The CC1310 device is the first part in a Sub-1-GHz family of cost-effective, ultra low power wireless MCUs. The CC1310 device combines a flexible, very low power RF transceiver with a powerful 48-MHz Cortex-M3 microcontroller in a platform supporting multiple physical layers and RF standards. A dedicated Radio Controller (Cortex-M0) handles low-level RF protocol commands that are stored in ROM or RAM, thus ensuring ultra low power and flexibility. The low-power consumption of the CC1310 device does not come at the expense of RF performance; the CC1310 device has excellent sensitivity and robustness (selectivity and blocking) performance.2. The CC1310 device is a highly integrated, true single-chip solution incorporating a complete RF system and an on-chip DC-DC converter.
Sensors can be handled in a very low-power manner by a dedicated autonomous ultra low power MCU that can be configured to handle analogue and digital sensors; thus the main MCU (Cortex-M3) is able to maximize sleep time.
The CC1310 power and clock management and radio systems require specific configuration and handling by software to operate correctly. This has been implemented in the TI RTOS, and it is therefore recommended that this software framework is used for all application development on the device. The complete TI-RTOS and device drivers are offered in source code free of charge.

Low Power CC1310 RF 434 MHz RTS Module UFL Connector 700m Reach

Pad Number	Name	Pin Type	Description
1	GND	Ground Pin	Connect to GND
2	DIO_1	Digital I/O	GPIO, Sensor Controller
3	DIO_2	Digital I/O	GPIO, Sensor Controller
4	DIO_3	Digital I/O	GPIO, Sensor Controller
5	DIO_4	Digital I/O	GPIO, Sensor Controller
6	DIO_5	Digital I/O	GPIO, Sensor Controller, High drive capability
7	DIO_6	Digital I/O	GPIO, Sensor Controller, High drive capability
8	DIO_7	Digital I/O	GPIO, Sensor Controller, High drive capability
9	GND	Ground Pin	Connect to GND
10	VDD	Power	1.8V to 3.8V main chip supply
11	DIO_8	Digital I/O	GPIO
12	DIO_9	Digital I/O	GPIO
13	DIO_10	Digital I/O	GPIO
14	DIO_11	Digital I/O	GPIO
15	DIO_12	Digital I/O	GPIO
16	DIO_13	Digital I/O	GPIO
17	DIO_14	Digital I/O	GPIO
18	DIO_15	Digital I/O	GPIO
19	JTAG_TMSC	Digital I/O	JTAG TMSC, High drive capability
20	JTAG_TCKC	Digital I/O	JTAG TCKC
21	DIO_16	Digital I/O	GPIO, JTAG_TDO, High drive capability
22	DIO_17	Digital I/O	GPIO, JTAG_TDI, High drive capability
23	DIO_18	Digital I/O	GPIO
24	DIO_19	Digital I/O	GPIO
25	DIO_20	Digital I/O	GPIO
26	DIO_21	Digital I/O	GPIO
27	DIO_22	Digital I/O	GPIO

Low Power CC1310 RF 434 MHz RTS Module UFL Connector 700m Reach

FAQ
 Q1: Are you a factory or trade company?
 A1: We are a professional factory with 25 years experience.
 Q2: Can you accept OEM/ODM?
 A2: Sure, we have rich OEM&ODM experience.
 Q3: Do you have quality assurance?
 A3; Each of our products has undergone quality testing and has two years of free after-sales service.
